Doorbell Camera Hub G410
Model
CH-C09D / CH-C09E
Dimensions
Main Unit: 141.5 x 65 x 30.4 mm (5.57 x 2.56 x 1.20 in) Chime/Hub: 65.2 x 65 x 28.4 mm (2.57 x 2.56 x 1.12 in)
Battery
6 * LR6 AA alkaline battery (Replaceable)
Local Storage
MicroSD card (not included). CLASS 10 or above is supported, up to 512 GB storage.
Power Input
Main Unit: 12V-24V AC 0.2A 50/60Hz or 12V-24V DC 0.5A (optional) Chime/Hub: 5V DC 1A (USB-C)
Wireless Protocols
Zigbee / Thread IEEE 802.15.4 (acts as a mesh extender), Wi-Fi IEEE 802.11 b/g/n/a/ac 2.4/5GHz, Bluetooth
Operating Temperature
Main Unit: -18°C ~ +50°C (0°F ~ 122°F) Chime/Hub: 0°C ~ +40°C (32°F~ 104°F)
Operating Humidity
0 ~ 90% RH, no condensation
What's in the box
Doorbell Camera Hub G410 × 1, Chime Repeater × 1, User Manual × 2, USB-C to USB-A Cable × 1, AA Battery × 6, Screwdriver × 1, Wall Screws & Anchors Kit × 1, Wedge Screws Kit × 1, 20° Wedge Bracket × 1
